Planet FNSW-2400PS - LAN SWITCH 24-PORT 10/100 POE

Chargement...Chargement...
-36%
LAN SWITCH 24-PORT 10/100 POE FNSW-2400PS

Prix Normal : 4 956,00 Dh HT

Prix :3 937,50 Dh HT

Prix Promo : 3 150,00 Dh HT

3 780,00 Dh TTC

Economie : 1 806,00 Dh - 36%

24-Port 10/100 Web/Smart Ethernet POE Switch

Disponibilité : Nous consulter sur mv.ma
Evaluation :
  • LAN SWITCH 24-PORT 10/100 POE FNSW-2400PS
  • FNSW-2400PS
  • FNSW-2400PS

Specification

ModelFNSW-2400PS
Hardware Specification

Ports24 10/100Base-TX RJ-45 Auto-MDI/MDI-X interfaces
Switch Processing SchemeStore-and-Forward
Throughput (packet per second)3.57Mpps@64Bytes
Switch Fabric4.8Gbps
Address Table8K entries
Share Data Buffer1.75Mb embedded memory for packet buffers
Flow ControlBack pressure for Half Duplex, IEEE 802.3x Pause Frame for Full Duplex
Dimension (W x D x H)445 x 207 x 45 mm (1U height)
Weight2.55kg
Power Requirement100~240V AC, 50-60 Hz, 2A
Power Consumption / DissipationMax.135 Watts / 460 BTU
Smart Function

System ConfigurationWeb interface, SNMP v1
Port ConfigurationPort Speed Duplex mode selection
Port Disable / Enable
Bandwidth ControlYes
Broadcast Storm ControlYes
Port StatisticsDisplay each port’s detail Ethernet traffic counter information
VLAN24 port-based VLAN groups / 32 IEEE 802.1Q VLAN groups / MTU VLAN
Spanning Tree ProtocolSTP, IEEE 802.1D (Spanning Tree Protocol)
RSTP, IEEE 802.1w (Rapid Spanning Tree Protocol)
Port Trunking2 groups of 4-Port 10/ 100Base-TX trunk support, up to 800Mbps bandwidth per trunk group
Port MirroringPort mirroring allows monitoring of the traffic across any port in real time
QoSAllows to assign low / high priority on each port
First-In-First-Out, All-High-before-Low, Weight-Round-Robin QoS policy
MAC Address / TCP & UDP FilterYes
IGMP Snooping v1 / v2Allows to Disable or Enable
Power over Ethernet
PoE StandardIEEE 802.3af Power over Ethernet / PSE
PoE Power Supply TypeMid-Span
PoE Power outputPer Port 48V DC, 350mA . Max. 15.4Watts
Power Pin Assignment4/5(-), 7/8(+)
PoE Power Budget
125Watts
Standards Conformance

Regulation ComplianceFCC Part 15 Class A, CE
Standards ComplianceIEEE 802.3 Ethernet
IEEE 802.3u Fast Ethernet
IEEE 802.3af Power over Ethernet (15.4Watts)
IEEE 802.3x Full-Duplex flow control
IEEE 802.1Q VLAN
IEEE 802.1p QoS
IEEE 802.1D Spanning Tree Protocol
IEEE 802.1w Rapid Spanning Tree Protocol

Friendly Web-Based Management
Web-Based Management

For efficient management, the FNSW-2400PS is equipped with remote Web interface. It can be programmed for advanced switch management functions such as port configuration, VLAN, Rapid Spanning Tree Protocol (RSTP), IGMP Snooping, port trunk, QoS, bandwidth control, and MAC address / TCP & UDP filter. The FNSW-2400PS provides Port-Based / IEEE 802.1Q / MTU VLAN (port based / IEEE 802.1Q VLAN including overlapping). The VLAN groups allowed on the FNSW-2400PS will be maximally up to 24 for port based or up to 32 for IEEE 802.1Q VLAN groups. On the other hand, the MTU VLAN divides port 1 to port 24 as separate LAN group. Via supporting port trunking, the FNSW-2400PS allows the operation of a high-speed trunk combining multiple ports. The FNSW-2400PS also provides two groups of up to 4-Port 10/ 100Base-TX trunk support with up to 800Mbps bandwidth per trunk group.

Environment

TemperatureOperating: 0~50 Degree C
Storage: -10~70 Degree C
Humidity

























Operating: 5~95%
Storage: 5~95% (Non-condensing)




FNSW-2400PS
