Planet FNSW-2400PS
Menu-
LAN SWITCH 24-PORT 10/100 POE
En Stock
4 956,00 Dh HT
3 937,50 Dh HT
4 725,00 Dh TTC
Specification
Model FNSW-2400PS Hardware Specification
Ports 24 10/100Base-TX RJ-45 Auto-MDI/MDI-X interfaces Switch Processing Scheme Store-and-Forward Throughput (packet per second) 3.57Mpps@64Bytes Switch Fabric 4.8Gbps Address Table 8K entries Share Data Buffer 1.75Mb embedded memory for packet buffers Flow Control Back pressure for Half Duplex, IEEE 802.3x Pause Frame for Full Duplex Dimension (W x D x H) 445 x 207 x 45 mm (1U height) Weight 2.55kg Power Requirement 100~240V AC, 50-60 Hz, 2A Power Consumption / Dissipation Max.135 Watts / 460 BTU Smart Function
System Configuration Web interface, SNMP v1 Port Configuration Port Speed Duplex mode selection
Port Disable / EnableBandwidth Control Yes Broadcast Storm Control Yes Port Statistics Display each port’s detail Ethernet traffic counter information VLAN 24 port-based VLAN groups / 32 IEEE 802.1Q VLAN groups / MTU VLAN Spanning Tree Protocol STP, IEEE 802.1D (Spanning Tree Protocol)
RSTP, IEEE 802.1w (Rapid Spanning Tree Protocol)Port Trunking 2 groups of 4-Port 10/ 100Base-TX trunk support, up to 800Mbps bandwidth per trunk group Port Mirroring Port mirroring allows monitoring of the traffic across any port in real time QoS Allows to assign low / high priority on each port
First-In-First-Out, All-High-before-Low, Weight-Round-Robin QoS policyMAC Address / TCP & UDP Filter Yes IGMP Snooping v1 / v2 Allows to Disable or Enable Power over Ethernet PoE Standard IEEE 802.3af Power over Ethernet / PSE PoE Power Supply Type Mid-Span PoE Power output Per Port 48V DC, 350mA . Max. 15.4Watts Power Pin Assignment 4/5(-), 7/8(+) PoE Power Budget 125Watts Standards Conformance
Regulation Compliance FCC Part 15 Class A, CE Standards Compliance IEEE 802.3 Ethernet
IEEE 802.3u Fast Ethernet
IEEE 802.3af Power over Ethernet (15.4Watts)
IEEE 802.3x Full-Duplex flow control
IEEE 802.1Q VLAN
IEEE 802.1p QoS
IEEE 802.1D Spanning Tree Protocol
IEEE 802.1w Rapid Spanning Tree Protocol
Friendly Web-Based ManagementWeb-Based Management For efficient management, the FNSW-2400PS is equipped with remote Web interface. It can be programmed for advanced switch management functions such as port configuration, VLAN, Rapid Spanning Tree Protocol (RSTP), IGMP Snooping, port trunk, QoS, bandwidth control, and MAC address / TCP & UDP filter. The FNSW-2400PS provides Port-Based / IEEE 802.1Q / MTU VLAN (port based / IEEE 802.1Q VLAN including overlapping). The VLAN groups allowed on the FNSW-2400PS will be maximally up to 24 for port based or up to 32 for IEEE 802.1Q VLAN groups. On the other hand, the MTU VLAN divides port 1 to port 24 as separate LAN group. Via supporting port trunking, the FNSW-2400PS allows the operation of a high-speed trunk combining multiple ports. The FNSW-2400PS also provides two groups of up to 4-Port 10/ 100Base-TX trunk support with up to 800Mbps bandwidth per trunk group.
Environment
Temperature Operating: 0~50 Degree C
Storage: -10~70 Degree CHumidity Operating: 5~95%
Storage: 5~95% (Non-condensing)
