24-port 10/100/1000M PoE Switch, 16 10/100/1000M RJ45 ports,managed
Obsolète (Fin de vie)Ce produit n'est plus proposé à la vente
FICHE TECHNIQUE
Descriptions du Produit
VM-S1024PEG-C 24-port 10/100/1000M POE Switch provides the seamless network connection. It integrates 10/100/1000Mbps Ethernet network capabilities. These POE ports can automatically detect and supply power with those IEEE 802.3at compliant Powered Devices (PDs). In this situation, the electrical power is transmitted along with data in one single cable allowing you to expand your network where there are no power lines or outlets, where you wish to fix devices such as APs, IP Cameras or IP Phones, etc.Features
Complies with IEEE802.3, IEEE 802.3u, IEEE 802.3ab standards24 x 10/100/1000Mbps Auto-Negotiation RJ45 ports supporting Auto-MDI/MDIXSupports PoE power up to 30W for each PoE portSupports ALL power up to 260WSupports PoE IEEE802.3at compliant PDsSupports IEEE802.3x flow control for Full-duplex Mode and backpressure for Half-duplex Mode16K entry MAC address table of the VM-S2024PEG with auto-learning and auto-agingLED indicators for monitoring power, link, activity and speedInternal power adapter supplySPECIFICATIONS
VM-S1024PEG-C
Chipset
RTL8389L + RTL8218+RTL8231
IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3at, IEEE 802.3af
10BASE-T: UTP category 5 cable (maximum 100m) 100BASE-T: UTP category 5 cable (maximum 100m)
1000Base-T: UTP category 5, 5e cable (maximum 100m)
Number of Ports
24 x 10/100/1000Mbps Auto-Negotiation ports
LED indicators
Port
Link/Act
POE
POE
Other
Power
Transfer Method
Store-and-Forward
16K
Switching Capacity
48Gbps
10Mbps: 14880pps
100Mbps: 148800pps
1000Mbps: 1488000pps
Dimensions (L × W × H)
442*208*44 mm
Environment
Operating Temperature: 0℃~40℃
Storage Temperature: -10℃~70℃
Operating Humidity: 10%~90% non-condensing
Storage humidity: 5%~90% non-condensing
